| Quantity: | |
|---|---|
LB-5Cubic
LEABON
| Model | 9TMRW-5 | 9TMRW-9 | 9TMRW-12 |
| Motor Power(kw) | 15 | 22 | 30 |
| Capacity(kg/h) | 2000-3000 | 4000-5000 | 6000-7000 |
| QTY of blades(PCS) | 40 | 58 | 69 |
| QTY of twisted dragon(PCS) | 3 | 3 | 3 |
| Reducer | Jiangsu Guomao R137 | Jiangsu Guomao R147 | Jiangsu Guomao R149 |
| Side plate thickness(mm) | 5 | 6 | 6 |
| Thickness of bottom plate(mm) | 6 | 8 | 10 |
| Dimension(mm) | 3900*1800*2100 | 4600*2000*2500 | 5300*2200*2600 |
| Weight（kg） | 2300 | 3200 | 4100 |
Work Principle:
Vertical full-mixing dietary mixer is mainly composed of one or two screw-shaped, and the spiral twisted dragon is divided into upper and lower spin. During the mixing and stirring, the material from both ends of the box at the same time all directions to the middle of the mixer peeling stirring. Each helix of the screwdriver is equipped with a moving blade to cut the fixed tooth at the position of the center line of the feed mixer, and cut and agitate all kinds of fibrous forages and stalks passed through, so as to achieve the complete mixing and crushing and dietary feeding effect.
| Model | 9TMRW-5 | 9TMRW-9 | 9TMRW-12 |
| Motor Power(kw) | 15 | 22 | 30 |
| Capacity(kg/h) | 2000-3000 | 4000-5000 | 6000-7000 |
| QTY of blades(PCS) | 40 | 58 | 69 |
| QTY of twisted dragon(PCS) | 3 | 3 | 3 |
| Reducer | Jiangsu Guomao R137 | Jiangsu Guomao R147 | Jiangsu Guomao R149 |
| Side plate thickness(mm) | 5 | 6 | 6 |
| Thickness of bottom plate(mm) | 6 | 8 | 10 |
| Dimension(mm) | 3900*1800*2100 | 4600*2000*2500 | 5300*2200*2600 |
| Weight（kg） | 2300 | 3200 | 4100 |
Work Principle:
Vertical full-mixing dietary mixer is mainly composed of one or two screw-shaped, and the spiral twisted dragon is divided into upper and lower spin. During the mixing and stirring, the material from both ends of the box at the same time all directions to the middle of the mixer peeling stirring. Each helix of the screwdriver is equipped with a moving blade to cut the fixed tooth at the position of the center line of the feed mixer, and cut and agitate all kinds of fibrous forages and stalks passed through, so as to achieve the complete mixing and crushing and dietary feeding effect.
