SZLH A B C Series Ring Die Feed Pellet Machine

Quantity:
  • SZLH-ABC
  • LEABON
                                                       SZLH A B C Series Ring Die Feed Pellet Machine
Introduction

SZLHA Series Ring Mould Pellet Mill is the main machine of making granular fodder, it can be used to make various roughage and refined fodder in livestock farm and feed mill, and also used for checmical industry, fertilizer industry and sugar industry.

Features

Parameter/Model SZLH-15A SZLH-20A SZLH-25A
Output(kg/h) 100-200 500-700 1000-1200
Power (kw) 3 11 22
Revolving Speed of ring die (r/min) 420 306 306
Inside diameter of ring die(mm) 150 200 250
Pellet diameter(mm) Φ1.5Φ2Φ2.5Φ3Φ3.5Φ4Φ5Φ6Φ8
Dimension(m) 0.75*0.45*0.8 1.1*1.15*1.25 1.1*1.15.1.25
Weight(kg) 175 500 625

SZLH B Series Ring Mould Pellet Mill is the main machine of making granular fodder, it can be used to make various roughage and refined fodder in livestock farm and feed mill, and also used for chemical industry, fertilizer industry and sugar industry.


Specification
Model No. SZLH-20B SZLH-25B SZLH-30B
Output(kg/h) 500-700 1000-1500 1500-2000
Power (kw) 11 22 30
Feeding motor(kw) 0.75 0.75 0.75
Revolving Speed of ring die (r/min) 306 306 330
Inside diameter of ring die(mm) 200 250 304
Pellet diameter(mm) Φ1.5Φ2Φ2.5Φ3Φ3.5Φ4Φ5Φ6Φ8
Dimension(m) 1.1*1.5*1.52 1.1*1.15*1.25 1.35*1.3*1.6
Weight(kgs) 580 710 960
Introduction
SZLH C series Ring Mould Pellet Mill is the main machine of making granular fodder, it can be used to make various roughage and refined fodder in livestock farm and feed mill, and also used for checmical industry, fertilizer industry and sugar industry.


Specification

Parameter/Model SZLH-20C SZLH-25C SZLH-30C
Output(kg/h) 600-800 1000-2000 1500-2000
Power (kw) 11 22 30
Feeding+Conditioner motor(kw) 0.75+1.1 0.75+1.1 0.75+1.1
Revolving Speed of ring die (r/min) 306 306 330
In-side diameter of ring die(mm) 200 250 304
Pellet diameter(mm) Φ1.5Φ2Φ2.5Φ3Φ3.5Φ4Φ5Φ6Φ8
Dimension(m) 1.1*1.86*1.6 1.1*1.86*1.6 1.35*1.88*1.65
Weight(kgs) 720 900 1035
Note: Above capacity is base on producing chicken feed with the 5mm ring die, if you want to produce
      different feed or different size feed pellet, please kindly inform in advance.


PRODUCT INQUIRE
Good quality-ontime delivery-good service
Leabon Equipment
1)We are the professional manufacturer, which has abundant experience of the machine, also we own research and development team.

2) The professional and timely 24 hours after-sale service.

3) The relative manual and video of the machine installation and instruction will be provided for you.

4) ODM&OEM Provided.

5) The engineer is available to  install and training for oversea projects.
