TBLM
LEABON
Features
The filter bag device adopts cage type filter bag, knitting polyester filter bag.
Straight-through solenoid valve, large pulse dust catcher bottom is equipped with twisted dragon, guan wind, reduce the process arrangement.
The dust removal efficiency up to 99%.
Has a unique match blowing device, using the framework of disassembly type bag structure, easy maintenance.
Technical parameter
Parameter | TBLM4 | TBLM6 | TBLM9 | TBLM12 | TBLM15 | TBLM21 | TBLM28 | TBLM40 |
Bag quantity | 4 | 6 | 9 | 12 | 15 | 21 | 28 | 40 |
Air Volume (m³/h) | 600-800 | 1200-2100 | 1900-3200 | 2100-3600 | 3200-4500 | 3700-6300 | 5800-8400 | 8400-12000 |
Compressed air Pressure (mpa) | 0.5-.07 | 0.5-0.7 | 0.5-0.7 | 0.5-0.7 | 0.5-.07 | 0.5-.07 | 0.5-.07 | 0.5-.07 |
Air consumption(L/min) | 28 | 42 | 63 | 84 | 105 | 147 | 196 | 280 |
Dust removing rate(%) | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% | 99.9% |
