Features
New controller with high precision can display the total weight, number of package, easy operation.
The adaptive software, having the function of automatic control parameters setting, automatic drop revising, over-weight warning and auto-diagnosis.
Wide packing range, it can match well with conveyor and sewing machine
Adopt imported sensor, pneumatic actuator, easy maintenance and non-pollution.
The main materials body is carbon steel, with painted plastic. And material contact part is stainless iron, corrosion resistance, long service life
Communication interface can be offered if need, realization of data communication with PC
Specification
Model Name | DB-1 | DB-5 | DB-25 | DB-50 | DB-100 |
Packing Range | 0.2-1kg | 1-5kg | 2.5-25kg | 5-50kg | 10-100kg |
Packing Error | 0.2%F.S | 0.2%F.S | 0.1 %F.S | 0.1 %F.S | 0.1 %F.S |
Packing Speed | 300-500 bags/h | 300-500 bags/h | 300-420 bags/h | ≥300 bags/h | ≥ 300 bags/h |
Division Value | 2g | 5g | 10g | 20g | 20g |
Power | AC 220V 50Hz | ||||
Air Supply | 0.4-0.8 MPa | ||||
Machine Dimension | 1725x620x710 (mm) | 1890x620x710 (mm) | 2450x650x715 (mm) | 2560x650x715 (mm) | 2960x730x775 (mm) |
Actuator | pneumatics | ||||
Accuracy Class | X(0.2) X(0.1) |
