LBA070T80
LEABON
Large-scale Vertical Four-side Door Opening Type Balers
Product Description
This model is designed for pressing and packaging materials with higher rebound force including rigid plastics,PET bottles, hay,fibers,sponges,cloths and others.
Heavy-duty vertical hydraulic baler with double-cylinder balance compressing design, and extraordinary hydraulic system to provide continuous stable force during compression. It generates greater compression force to bale larger loads, four sides opening style with"#" shape strapping capability,also allows the materials to be packaged before strapping. Chamber anti-rebound device can be optionally installed.
Technical parameter:
Model | LBA070T80 | LBA070T120 | LBA1010T160 |
Hydraulic Power(Ton) | 80 | 120 | 160 |
Bale Size(L*W*H) mm | 1000*700*(500-900) | 1000*700*(500-900) | 1100*1000*(400-1200) |
Feed Opening size(L*H)mm | 1000*500 | 1000*500 | 1100*800 |
Chamber Size(L*W*H)mm | 1000*700*1500 | 1000*700*1500 | 1100*1000*2000 |
output(Bales/hr) | 4-6 | 4-6 | 4-6 |
Voltage(Customizable)(/Hz) | 380/50 | 380/50 | 380/50 |
Power(KW/HP) | 11/15 | 15/20 | 30/40 |
Machine Size(L*W*H) mm | 1800*1480*3500 | 2100*1700*3500 | 2100*1800*4600 |
Machine Weight(KG) | 2600 | 3200 | 6000 |
✽The above parameters can be customized according to customer's requirement.
