LBW-K5
LEABON
Horizontal (weight-fixed) compression Bagging Machine
Product Description
Designed for bagging and compressing fabrics,fiber, and many other similar materials. Compression and bagging are completed in one continuous integrated motion,increasing productivity and efficiency. Weighing and counting function helps to consistently control the baled materials effectively，safety interlock and button control enhance work safety and efficiency.
Technical parameter:
Model | LBW-K5 | LBW-K10 | LBW-K15 | LBW-K20 | LBW-K25 |
Bale Size(L*W*H) mm | 400*300*100 | 400*400*180 | 550-400*250 | 550*450*250 | 600*450*250 |
Bale Weight(KG) | 5 | 10 | 15 | 20 | 25 |
Voltage(Customizable)(V/Hz) | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
Power(KW/HP) | 5.5/7.5 | 5.5/7.5 | 5/10 | 7.5/10 | 11/15 |
Machine Size(L*W*H) mm | 2600*1750*1480 | 2660*1760*1550 | 2750*1810*1550 | 2980*2015*1550 | 32102330*1550 |
Machine Weight(KG) | 765 | 815 | 870 | 950 | 1050 |
Package Size(W*H)mm | 400*620 | 580*700 | 650*1000 | 700*1000 | 700*1050 |
✽The above parameters can be customized according to customer's requirement
Horizontal (weight-fixed) compression Bagging Machine
Product Description
Designed for bagging and compressing fabrics,fiber, and many other similar materials. Compression and bagging are completed in one continuous integrated motion,increasing productivity and efficiency. Weighing and counting function helps to consistently control the baled materials effectively，safety interlock and button control enhance work safety and efficiency.
Technical parameter:
Model | LBW-K5 | LBW-K10 | LBW-K15 | LBW-K20 | LBW-K25 |
Bale Size(L*W*H) mm | 400*300*100 | 400*400*180 | 550-400*250 | 550*450*250 | 600*450*250 |
Bale Weight(KG) | 5 | 10 | 15 | 20 | 25 |
Voltage(Customizable)(V/Hz) | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
Power(KW/HP) | 5.5/7.5 | 5.5/7.5 | 5/10 | 7.5/10 | 11/15 |
Machine Size(L*W*H) mm | 2600*1750*1480 | 2660*1760*1550 | 2750*1810*1550 | 2980*2015*1550 | 32102330*1550 |
Machine Weight(KG) | 765 | 815 | 870 | 950 | 1050 |
Package Size(W*H)mm | 400*620 | 580*700 | 650*1000 | 700*1000 | 700*1050 |
✽The above parameters can be customized according to customer's requirement
